Servo Power Feed Replacement Parts Types, 140,150,200

Used on Servo Product Co. Power Feeds.

( Please double click on pictures twice for a larger view.)

Zytel Gear and Hub Ass'y Used on all Servo Product Co. Type Power Feeds. Recommend purchasing Bottom Cover. 4737	Drive Pin, for Spur Gear Used on all Servo Product Co. Power Feeds. 1788	5/16-24 Hex Locknut Used on all Servo Product Co. Power Feeds. 01009
Circuit Breaker Switch 1.8 AMP. Used on Servo Product Co. Power Feed Type: 70. 01149	Circuit Breaker Switch 3.0 AMP. Used on Servo Product Co. Power Feed Types: 80, 100, 140, 150 04103-K	Circuit Board Ass'y Used on Servo Product Co. Power Feeds Types: 100, 150. 5567
Circuit Board Ass'y Used on Servo Product Co. Power Feeds Types: 80, 140, 200. 5087	Armature & Bearing Ass'y Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150. 1767-4	Bevel Gear Bevel Gear Used on All Servo Product Co. Power Feeds. Other Bevel Gears Available for vairous Milling Machine Types. Please call us at 1-800-726-8438 for Part numbers and prices. Recommend purchashing Shim Kit Part # A-0589. 0237
Shim Kit Used with Bevel Gears on Servo Product Co. Power Feeds. A-0589	Motor Field Ass'y Used on Servo Product Co. Power Feeds Types: 100, 150. 1766-2	Motor Field Ass'y Used on Servo Product Co. Power Feeds Type: 140. 1786-4
Slotted Screw Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150. 8-32 x 2-3/4 Phil. HD. 2 Req'd. 03034	Brush Cap Used on all Servo Product Co. Power Feeds. 00573	Brush Motor Used on all Servo Products Co. Power Feeds. 01283
Brush Holder Used on all Servo Products Co. Power Feeds. 01282	Limit Switch Ass'y Used on Servo Product Co. Power Feed Types: 100,150. Recommend Purchasing: (4) Part # 00577 Screws, and (1) Part # 4894 Strain Relief. 2024-7	Limit Switch Ass'y Used on Servo Product Co. Power Feeds Types: 80, 140, 200 Recommend Purchasing (1) Part# 4894 Strain Relief, (4) Part# 00577 Screws. 2023-10
Strain Relief Used on Servo Products Co. Power Feeds Types: 80, 100, 140, 150, 200. 4894	Screws Used on all Servo Products Co. Type Power Feeds. 4 Req'd. 4-40 x 7/8" Phil. Pan. HD. Sc. 00577	Hex Seal Boot Used on Servo Product Co. Power Feeds Types: 70, 80, 90, 100, 140, 150, 200. 2499
Rapid Switch Plunger Ass'y. (complete) Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150, 200. Includes: Part #'s 4883, 03039, 4884, 03040, 03038 5882	Reversing Switch Ass'y Used on Servo Product Co. Power Feeds Types: 100, 150 5571	Reversing Switch Ass'y Used on Servo Products Co. Power Feeds Types: 140, 200 5091-2
Reversing Switch Ass'y Used on Servo Product Co. Power Feed Type: 80. 5091	Actuator Switch Used on Servo Products Co. Power Feeds Types: 80, 100, 140, 150, 200 5098	Switch Actuator Pin Used on Servo Products Co. Power Feeds Types: 80, 100, 140, 150, 200 4992
Potentiometer Ass'y Used on Servo product Co. Power Feeds Type: 150. 5568	Potentiometer Ass'y Used on all Servo Products Co. Power Feeds Types: 80, 140, 200 5085	Name Plate Used on Servo Product Co. Power Feeds Type 140. 6262-2
Control Handle Ass'y Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150. 4918	Bottom Housing Used on Servo Product Co. Power Feeds Types: 140, 150, 200 4853-12	Top Bearing Mount Used on Servo Product Co. Power Feeds Types: 80,100,140,150, 200 4891-2
Spring Washer Used on Servo Product Co. Power Feeds. 00555	Top Housing Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150, 200 4854-14	Needle Bearing Used on Servo Product Co. Power Feeds. 00650
Control Handle Knob. (Ball) Used on Servo Product Co. Power Feeds Types: 80,100, 140, 150, 200 01043	Needle Bearing Used on all Servo Product Co. Power Feeds. 00502	Upper Drive Shaft Spacer Used on all Servo Product Co. Power Feeds. 1364
Retaining Ring Used on all Servo Product Co. Power Feeds. 00983	Power Cord Ass'y Used on Servo Product Co. Power Feeds Types: 100,150. Recommend Purchasing: (1) Part # 4894 Strain Relief. 5071	Power Cord Ass'y Used on Servo Products Co. Power Feeds Types: 140,200. Recommend Purchasing: (1) Part # 4894 Strain Relief. 5089
Tetra Seal Used on all Servo Product Co. Power Feeds. 00984	Name Plate Type 150 Used on Servo Product Co. Power Feeds Type: 150. 6262	Bearing Sized Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150, 200 01221
Insulator Brush Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150, 200 5387	Bottom Cover Used on all Servo Product Co. Type Power Feeds. 2974	Micro Switch Used on all Servo Products Co. Power Feeds. 01241
Micro Switch Actuator Used on all Servo Products Co. Type Power Feeds. Min. 2 Req'd. 1557	Speed Control Knob Used on all Servo Product Co. Type Power Feeds. 6225	Lift Fork Ass'y Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150. 4913
Lift Fork spring Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150, 200 5528	Drive Shaft Ass'y - Upper Used on all Servo Product Co. Power Feeds. 3509	Cam Ass'y Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150, 200 5530-2
Light Pipe for Top Housing Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150, 200 5064	Pilot Light Mtg. Grommet Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150, 200 03103	Circuit Board Insulator Used on Servo Product Co. Power Feeds Types: 80, 100, 140, 150, 200 6193
Rapid Switch Ass'y Used on Servo Product Co. Power Feeds Types: 140. 5092	Tolerance Ring Used on Servo Product Co. Power Feeds. 00982	SCR Used on All Servo Product Co. Power Feeds. 01265
